Flight — 355.6mm
355.6 mm outer diameter screw flight, 254 mm pitch, 63.5 mm ID — left-hand flighting for auger assemblies.
| outer diameter mm | 355.6 |
| pitch mm | 254 |
| inner diameter mm | 63.5 |
| flight thickness mm | 5 |
| flight hand | Left |
| material | Mild Steel (fabricated flight plate) |
| manufacturing process | Plate forming, rolling, welding and dressing |
| surface finish | Dressed welds and protective coating |
| application | Auger flight for conveyors and grain handling; fits Ø63.5 mm pipe core; left-hand flight |
Description
This 355.6 mm OD flight is a formed and welded auger flight segment produced for medium-to-heavy duty auger assemblies. It features a 254 mm pitch, 63.5 mm internal diameter and left-hand flight direction for application-specific rotation. Manufactured from mild steel plate, the flight is rolled, seam-welded and dressed ready for installation onto a matching pipe core. Supplied as a replacement flight or fabrication element for conveyors, grain-handling and material transfer systems, it is suitable for both repair and new build applications where left-hand geometry is required.
Use Cases
- Replacement flight for medium-to-heavy duty augers
- Fabrication element for auger assembly and repairs
- Used in conveyors, grain handling and material transfer systems
